PHX OpenCap — Data Export & Field Reporting Ecosystem

Chrome Extension + Excel VBA Dashboard Bridging wellsite data capture, office reporting, and equipment lifecycle tracking.

Overview

PHX OpenCap is an independent toolset that extracts operational drilling data from the FieldCap web application and delivers it into structured formats for downstream use in Excel-based field reports, custom dashboards, and (planned) web-based office/field ecosystems.

The system consists of two main components:

Component	Location	Purpose
Chrome Extension	`src/chrome-extension/`	Extracts job, crew, BHA equipment, and daily slide/rotate metre data from FieldCap via OData API
Excel VBA Module	`src/excel/MDL_DDTools.bas`	Imports exported CSVs and renders an interactive DD Tools dashboard with BHA selectors, hour/meter tracking, and fatigue warnings

Architecture

┌─────────────────────────────────────────────────────────────────┐
│                    FieldCap Web Application                       │
│              (PHX Technology — phxtech.com)                       │
└────────────────────────┬────────────────────────────────────────┘
                         │  OData v4 API + XHR/Fetch Interception
                         ▼
┌─────────────────────────────────────────────────────────────────┐
│              Chrome Extension (Manifest V3)                       │
│  ┌──────────┐  ┌──────────────┐  ┌───────────────────────────┐  │
│  │content.js│  │injected-spy.js│  │    background.js          │  │
│  │DOM scrape│  │XHR/Fetch hook │  │  OData fetch + normalize  │  │
│  └────┬─────┘  └──────┬───────┘  │  CSV generation           │  │
│       │               │          │  ActivityLog metre parsing │  │
│       └───────────────┴──────────┤                            │  │
│                                  └────────────┬───────────────┘  │
│                                               │                  │
│  ┌──────────────────────────────────────────┐ │                  │
│  │           popup.js + popup.html          │ │                  │
│  │  • Job ID input                          │◄┘                  │
│  │  • 4-checkbox export selector            │                    │
│  │  • Fetch & Build CSVs                    │                    │
│  │  • File System Access API download       │                    │
│  │  • Per-export status cards               │                    │
│  └──────────────────────┬───────────────────┘                    │
└─────────────────────────┼────────────────────────────────────────┘
                          │  4 CSV files
                          ▼
┌─────────────────────────────────────────────────────────────────┐
│                    Local File System                              │
│  fieldcap-job-{id}-job-details.csv                               │
│  fieldcap-job-{id}-crew.csv                                      │
│  fieldcap-job-{id}-bha-equipment.csv                             │
│  fieldcap-job-{id}-slide-rotate-metres-by-day.csv                │
└─────────────────────────┬────────────────────────────────────────┘
                          │  VBA Refresh import
                          ▼
┌─────────────────────────────────────────────────────────────────┐
│              Excel DD Tools Dashboard                             │
│  • Interactive BHA selector buttons                              │
│  • Per-BHA stats: meters, hours (slide/rot/circ), fatigue        │
│  • Cumulative serial-hour tracking with 300hr limit warnings     │
│  • Raw BHA Summary table (for VLOOKUP formulas)                  │
│  • Slide Meters / Rotate Meters breakdown                        │
└─────────────────────────────────────────────────────────────────┘

Chrome Extension

What It Does

Fetches job details, crew schedules, BHA equipment data, and daily slide/rotate metre totals directly from FieldCap’s OData API using your active browser session — no separate login needed.
Intercepts FieldCap’s own internal API calls (XHR/Fetch) to capture hour statistics and metric fields not exposed on the public OData endpoints.
Scrapes the visible DOM (BHA grid) to capture real-time component values.
Generates 4 clean, properly-typed CSV files ready for Excel or any downstream system.

CSV Outputs

File	Contents
`fieldcap-job-{id}-job-details.csv`	Core job metadata + all custom field key-value pairs
`fieldcap-job-{id}-crew.csv`	One row per crew member with role, contact, dates
`fieldcap-job-{id}-bha-equipment.csv`	One row per BHA component with serial, hours, meters, fatigue data
`fieldcap-job-{id}-slide-rotate-metres-by-day.csv`	Daily slide and rotate metres per BHA, sourced directly from ActivityLogs

Slide / Rotate Metres by Day

The slide-rotate-metres-by-day CSV is built directly from the FieldCap ActivityLogs OData endpoint — the same source that powers the Slide Sheet tab inside FieldCap. Each row represents one calendar day of drilling for a specific BHA.

Column	Description
`Job ID`	FieldCap job number
`Date`	Calendar date (`YYYY-MM-DD`) from `StartDateTime`
`BHA #`	BHA assembly number
`Slide Metres`	Sum of `End MD − Start MD` where `ActivityType = 'Sliding'`
`Rotate Metres`	Sum of `End MD − Start MD` where `ActivityType = 'Drilling'`
`Survey Course Sum`	Total of slide + rotate for the day

This replaces the previous SurveySheetEntries-based calculation which was producing incorrect (often doubled) totals. The ActivityLogs source exactly matches what FieldCap displays on its Slide Sheet tab.

BHA Equipment Columns

Job ID, BHA #, Section, Status, Motor, Guidance,
Metres Drilled, BHA Mtrs Slid, BHA Mtrs Rot,
BHA Total Hrs, BHA Hrs Slid, BHA Hrs Rot, BHA Hrs Circ, BHA Below Rot,
Activated On, Completed On,
Serial #, Item Code, Description, Sub Description,
Length, Accum Length, Top, Bottom, Max OD, Min ID,
Job Hours, HSLS, Strapped, Shipping Status, Dispatched On, Returned On

Installation

Open chrome://extensions (or edge://extensions).
Enable Developer mode.
Click Load unpacked → select src/chrome-extension/.
Navigate to FieldCap, ensure you’re logged in.
Click the extension icon, enter Job ID, and click Fetch & Build CSVs.

Usage Tips

All 4 export types are selected by default. Uncheck any you don’t need before fetching.
The popup shows 4 independent status cards — each updates as its data finishes fetching.
Slide/Rotate Metres by Day requires no special tab to be open; it is fetched entirely via OData.
live bhaRows and live activityRows counts in the status bar reflect DOM-captured data for the BHA equipment CSV.

Excel DD Tools Dashboard

What It Does

Imports the exported CSVs and renders a fully interactive directional drilling dashboard:

BHA selector buttons — embedded Form Control buttons in the header, one per BHA
Per-BHA statistics — total meters, slide/rotate meters, hours breakdown, below-rotate hours
Component detail table — serial numbers, descriptions, individual hours per tool
Cumulative serial-hour table — aggregates hours by serial number across all BHAs
300-hour fatigue warning — highlights components exceeding the hour limit with serial identification
Raw BHA Summary table — positioned for easy VLOOKUP formulas from other sheets

Installation

Open your Excel workbook.
Alt+F11 → File → Import File → select src/excel/MDL_DDTools.bas.
Run macro: RebuildDashboard (creates the DD Tools sheet structure).
Click Refresh button to import CSVs from the workbook’s directory.

How Refresh Works

Scans the workbook’s directory for CSVs matching bha-equipment, crew, job-details.
Always picks the newest file by timestamp when multiple versions exist.
Shows a confirmation dialog with filenames and timestamps before importing.
Imports to hidden data sheets (_FC_BHA, _FC_CREW, _FC_JOB).
Rebuilds the dashboard without changing your active sheet/cell focus.

See src/excel/DD_TOOLS_SETUP.md for detailed setup instructions.

Project Structure

PHX_FieldCap/
├── README.md
├── .gitignore
├── fieldcap-job-20786-*.csv          (sample exports — not committed)
│
└── src/
    ├── chrome-extension/
    │   ├── manifest.json             (Manifest V3, v3.1.1)
    │   ├── background.js            (OData fetch, CSV generation, ActivityLog parsing)
    │   ├── content.js               (DOM scraping, table detection, auto-scrape)
    │   ├── injected-spy.js          (page-context XHR/Fetch interception)
    │   ├── popup.html               (extension UI — PHX dark/teal theme, 4-export layout)
    │   ├── popup.js                 (popup logic, File System Access API downloads)
    │   └── icons/
    │       ├── icon16.png
    │       ├── icon48.png
    │       ├── icon128.png
    │       └── make_icons.ps1
    │
    ├── excel/
    │   ├── MDL_DDTools.bas           (DD Tools dashboard VBA module)
    │   └── DD_TOOLS_SETUP.md        (setup instructions)
    │
    ├── js/                           (legacy/diagnostic scripts)
    │   ├── fieldcap-bha-equipment-exporter.js
    │   ├── fieldcap-console-exporter.js
    │   ├── fieldcap-hour-field-diagnostic.js
    │   └── fieldcap-visible-table-exporter.js
    │
    └── vba/
        └── FieldCapInventoryMacro.bas (standalone inventory macro)

Changelog

v3.0.0 — Major Release

New export: Slide / Rotate Metres by Day — 4th CSV output sourced directly from the FieldCap ActivityLogs OData endpoint, exactly matching the FieldCap Slide Sheet tab.
- ActivityType = 'Sliding' → slide metres (End MD − Start MD)
- ActivityType = 'Drilling' → rotate metres (End MD − Start MD)
- Grouped by calendar date and BHA number
UI overhaul — popup now has 4 independent checkboxes and 4 status cards (one per export type)
Fixed: slide/rotate totals were previously calculated from SurveySheetEntries which produced incorrect (often doubled) values; now uses ActivityLogs as the authoritative source
Fixed: date parsing of FieldCap’s compact YYYYMMDDHHMI integer format (eliminated phantom 1976 dates)

v2.5.x

OData-driven export of job details, crew, and BHA equipment
File System Access API for direct-to-folder downloads
XHR/Fetch interception for hour statistics
DOM scraping fallback for activity metre data

Roadmap

Planned: Web Spreadsheet & Office Integration

Web-based spreadsheet interface — browser-native viewer/editor for field reports without Excel dependency
Real-time sync — push FieldCap exports directly to a shared web workspace
Template engine — populate custom report templates (daily drilling reports, BHA run reports, tool failure reports) from the same CSV data
Office 365 / Google Sheets bridge — auto-import into cloud spreadsheet platforms

Planned: Seamless Client Workflow

Field → Office pipeline — wellsite crew exports data; office receives formatted reports automatically
Equipment lifecycle tracking — serial-hour fatigue integrated with dispatch/return workflows
Service company integration — standardized data handoff for MWD/LWD tool rental tracking

Data Privacy

The extension operates using your existing FieldCap browser session — no credentials are stored or transmitted externally.
All data remains local (browser storage + local CSV files).
No telemetry, analytics, or external API calls beyond FieldCap’s own OData endpoint.

Disclaimer

This project (OpenCap) is an independent, unofficial tool. It is not affiliated with, endorsed by, or supported by PHX Technology, FieldCap, or any other third party. All trademarks and product names belong to their respective owners.

The name FieldCap is used solely to describe the third-party web application this tool interacts with. Use of that name does not imply any association or endorsement.
